THE M4

BMW 4 SERIES COUPÉ M AUTOMOBILES: ENGINES & TECHNICAL DATA.
BMW M4 CSL, BMW M4 Competition Coupé – engines, facts and dimensions.
The key facts and figures for the BMW M4 CSL, BMW M4 Competition Coupé at a glance: find out all about engines, consumption, CO2 emissions and dimensions of the various BMW 4 Series Coupé M Automobiles. Compare impressive performance data such as displacement, hp, Nm and acceleration – and discover which of these three exceptional sports coupés suits you best.
ENGINES AND TECHNICAL DATA OF THE BMW 4 SERIES COUPÉ M AUTOMOBILES.
- BMW M4 CSL Coupé
- BMW M4 Competition M xDrive Coupé
No search result found. Please try another input

Unladen weight EU in kg | 1,700 |
---|---|
Max. permissible weight in kg | 1,970 |
Permitted load in kg | 345 |
Permitted axle load front/rear in kg | 1,010/1,020 |
Luggage capacity min. (seats up) in l | 440 |
Luggage capacity max. (seats down) in l | - |
Trailer load (unbraked) in kg | - |
Trailer load 8% (braked) in kg | - |
Trailer load 12% (braked) in kg | - |
Cylinders/valves | 6/4 |
---|---|
Capacity in ccm | 2,993 |
Stroke/bore in mm | 90.0/84.0 |
Engine power in kW (hp) at 1/min | 405 (551)/6,250 |
Engine torque (Nm) at 1/min | 650/2,750-5,950 |
Compression ratio : 1 | 9.3 |
Top speed in km/h | 307 |
---|---|
Acceleration 0–100 km/h in s | 3.7 |
Urban in l/100 km | 14.0 |
---|---|
Extra-urban in l/100 km | 7.8 |
Combined in l/100 km | 10.1 |
CO2 combined emissions in g/km | 229 |
Tank capacity, approx. in l | 59 |
Tyre dimensions front | 275/35 ZR 19 (100Y) XL |
---|---|
Tyre dimensions rear | 285/30 ZR 20 (99Y) XL |
Wheel dimensions and material front | 9.5 J x 19 inches, light-alloy |
Wheel dimensions and material rear | 10.5 J x 20 inches, light-alloy |
Unladen weight EU in kg | 1,850 |
---|---|
Max. permissible weight in kg | 2,205 |
Permitted load in kg | 430 |
Permitted axle load front/rear in kg | 1,120/1,150 |
Luggage capacity min. (seats up) in l | 440 |
Luggage capacity max. (seats down) in l | - |
Trailer load (unbraked) in kg | - |
Trailer load 8% (braked) in kg | - |
Trailer load 12% (braked) in kg | - |
Cylinders/valves | 6/4 |
---|---|
Capacity in ccm | 2,993 |
Stroke/bore in mm | 90.0/84.0 |
Engine power in kW (hp) at 1/min | 375 (510)/6,250 |
Engine torque (Nm) at 1/min | 650/2,750-5,500 |
Compression ratio : 1 | 9.3 |
Top speed in km/h | 250 |
---|---|
Acceleration 0–100 km/h in s | 3.5 |
Urban in l/100 km | 14.1 |
---|---|
Extra-urban in l/100 km | 7.9 |
Combined in l/100 km | 10.2 |
CO2 combined emissions in g/km | 232 |
Tank capacity, approx. in l | 59 |
Tyre dimensions front | 275/35 ZR19 (100Y) XL |
---|---|
Tyre dimensions rear | 285/30 ZR20(99Y) XL |
Wheel dimensions and material front | 9.5Jx19 inches, light-alloy |
Wheel dimensions and material rear | 10.5 J x 20 inches, light-alloy |
Fuel consumption and CO2 emissions of the BMW 4 Series Coupé M Automobiles.
BMW M4 CSL:
Fuel consumption in l/100 km (combined): 10.1–9.8
CO2 emissions in g/km (combined): 227–222
BMW M4 Competition Coupé with M xDrive:
Fuel consumption in l/100 km (combined): 10.1–10.0
CO2 emissions in g/km (combined): 230–227
BMW M4 Competition Coupé:
Fuel consumption in l/100 km (combined): 9.8
CO2 emissions in g/km (combined): 224–223
BMW M4 Coupé:
Fuel consumption in l/100 km (combined): 10.1–9.9
CO2 emissions in g/km (combined): 230–226
BMW M440i Coupé:
Fuel consumption in l/100 km (combined): 8.1–7.4
CO2 emissions in g/km (combined): 184–167
BMW M440i xDrive Coupé:
Fuel consumption in l/100 km (combined): 8.2–7.5
CO2 emissions in g/km (combined): 186–170
BMW M440d xDrive Coupé:
Fuel consumption in l/100 km (combined): 6.3–5.7
CO2 emissions in g/km (combined): 165–150
Official data on fuel consumption and CO2 emissions were determined in accordance with the mandatory measurement procedure and comply with Regulation (EU) 715/2007 valid at the time of type approval. In case of a range, figures in the WLTP take into account any optional equipment. For newly type-tested vehicles since 01.01.2021, the official data no longer exist according to NEDC, but only according to WLTP. For more information on the WLTP and NEDC measurement procedures, see www.bmw.de/wltp
For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html.
Fuel consumption and CO2 emissions of the BMW 4 Series Coupé M Automobiles.
BMW M4 CSL:
Fuel consumption in l/100 km (combined): 10.1
CO2 emissions in g/km (combined): 229BMW M4 Competition Coupé with M xDrive:
Fuel consumption in l/100 km (combined): 10.2
CO2 emissions in g/km (combined): 232The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.
The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.
When charging times are shown they can be affected by a number of factors such as type of charger, voltage supplied to the charger/car and type of current (AC or DC) supplied to the charger/car. The car also plays a role in charging times as it can be set by the driver to accept various different amperage and should preconditioning be used to heat or cool the vehicle while charging this will also affect the charging time.
The basis for the calculation of the charging times for 100 km range is the electric consumption of the vehicle based on the use of a high-Powered Charging station (HPC) or charging type and current as indicted in the literature above. The testing procedure measures are based on a 23 degrees Celsius battery start and ambient temperature with certification values excluding additional auxiliary consuming devices and systems within the vehicle such as seat heating, displays, air conditioning.
Individual consumption (fuel economy) may differ due to driving profile, vehicle load profile, auxiliary consumer usage, temperature, and ambient conditions. Consumption is based on WLTP or NEDC (whichever is indicated) best case conditions and is independently tested for BMW Group. If you are comparing this range with other models or brands make sure they are stating the same WLTP or NEDC testing regime. These results can be used to compare vehicles on a close to “like for like” basis but are unlikely to be achieved in real world conditions for reasons including temperature variation, driving conditions and the use of the auxiliary systems referred to above.
Information provided and images displayed on this site include overseas models and may show some features not available in New Zealand. Please contact an authorised BMW dealer for specific information on vehicles and features available in New Zealand. Product changes may have been made since production of this content.
Note: To obtain NZ CO2 figures for vehicles imported by BMW Group NZ in relation to the NZ Clean Car discount or “FeeBate” you will need to contact your preferred dealer. The Clean Car discount figures sourced from your dealer will differ from those listed in the BMW owner’s handbook and reported figures as they have been converted by the NZ government to WLTP3 from figures derived through one of the following testing procedures: WLTP4 or NEDC or Japanese JC08 mode or Japanese 10-15 mode or CAFE test cycle.
For all vehicles not imported by BMW NZ (Used vehicle imports) you will need to contact the source market for these CO2 figures as BMW Group NZ has no access to and cannot source this CO2 data.
For more information on the New Zealand Clean Car Programme, please visit https://www.nzta.govt.nz/vehicles/clean-car-programme/
