BMW 3 series touring (G21), engines and dimensions

THE 3

BMW 3 SERIES TOURING: ENGINES & TECHNICAL DATA

Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW 3 Series Touring.

Read more
THE 3BMW 3 SERIES TOURING: ENGINES & TECHNICAL DATA

BMW 3 SERIES TOURING: TECHNICAL DATA.

Select model

Weight

Unladen weight EU in kg 1.645
Max. permissible weight in kg 2,135
Permitted load in kg 565
Permitted axle load front/rear in kg 975/1,260
Luggage capacity min. (seats up or roof down) in l 500
Luggage capacity max. (seats down or roof up) in l 1,510
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,600
Trailer load 12% (braked) in kg 1,600

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 135 (184)/5,000-6,500
Engine torque (Nm) at 1/min 300/1,350-4,000
Compression ratio : 1 11

Performance

Top speed in km/h 230
Top speed electrical in km/h -
Acceleration 0–100 km/h in s 7.5

Fuel consumption

Urban in l/100 km 7.8
Extra-urban in l/100 km 6.0
Combined in l/100 km 6.7
CO2 combined emissions in g/km 152
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/50 R17 98 Y XL
Tyre dimensions rear 225/50 R17 98 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (HP) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (HP) -
Combined torque Nm -

FUEL CONSUMPTION AND CO2 EMISSIONS.

BMW 330i Touring:
Fuel consumption in l/100 km (combined): 7,7–6,8
CO2 emissions in g/km (combined): 176–155



Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp

Read more
​

Fuel consumption and CO2 emissions.

  • 320i Touring:
    Fuel consumption in l/100 km (combined): 6.7
    CO2 emissions in g/km (combined): 152

    M340i xDrive Touring:
    Fuel consumption in l/100 km (combined): 8.0
    CO2 emissions in g/km (combined): 183

    The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.

    Further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html.

    Information provided and images displayed on this site include overseas models and features not available in New Zealand. Please contact an authorised BMW dealer for specific information on vehicles and features available in New Zealand. Product changes may have been made since production of this content.
