BMW 3 SERIES TOURING: ENGINES & TECHNICAL DATA

THE 3BMW 3 SERIES TOURING: ENGINES & TECHNICAL DATA

TECHNICAL DATA.

Weight
Unladen weight EU in kg
1.735
Max. permissible weight in kg
2,255
Permitted load in kg
595
Permitted axle load front/rear in kg
1,055/1,300
Luggage capacity min. (seats up or roof down) in l
500
Luggage capacity max. (seats down or roof up) in l
1,510
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
-
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
4/4
Capacity in ccm
1,995
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
140 (190)/4,000
Engine torque (Nm) at 1/min
400/1,750-2,500
Compression ratio : 1
16.5
Performance
Top speed in km/h
225
Acceleration 0–100 km/h in s
7.4
Fuel consumption
Urban in l/100 km
5.6
Extra-urban in l/100 km
5.0
Combined in l/100 km
5.2
CO2 combined emissions in g/km
137
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98 Y XL
Tyre dimensions rear
225/50 R17 98 Y XL
Wheel dimensions and material front
7,5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7,5 J x 17 inches, light-alloy
Weight
Unladen weight EU in kg
1.835
Max. permissible weight in kg
2.35
Permitted load in kg
590
Permitted axle load front/rear in kg
1,105/1,340
Luggage capacity min. (seats up or roof down) in l
500
Luggage capacity max. (seats down or roof up) in l
1,510
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
-
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
6/4
Capacity in ccm
2,993
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
195 (265)/4,000
Engine torque (Nm) at 1/min
580/1,750-2,750
Compression ratio : 1
16.5
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
5.4
Fuel consumption
Urban in l/100 km
6.9
Extra-urban in l/100 km
5.7
Combined in l/100 km
6.1
CO2 combined emissions in g/km
161
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/40 R19 93 Y XL
Tyre dimensions rear
255/35 R19 96 Y XL
Wheel dimensions and material front
8 J x 19 inches, light-alloy
Wheel dimensions and material rear
8.5 J x 19 inches, light-alloy
Weight
Unladen weight EU in kg
1.845
Max. permissible weight in kg
2.365
Permitted load in kg
595
Permitted axle load front/rear in kg
1,095/1,345
Luggage capacity min. (seats up or roof down) in l
500
Luggage capacity max. (seats down or roof up) in l
1,510
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
-
Trailer load 12% (braked) in kg
1,800
Engine
Cylinders/valves
6/4
Capacity in ccm
2,998
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
275 (374)/5,500-6,500
Engine torque (Nm) at 1/min
550/1,800-5,000
Compression ratio : 1
10.2
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
4.5
Fuel consumption
Urban in l/100 km
10.3
Extra-urban in l/100 km
6.7
Combined in l/100 km
8.0
CO2 combined emissions in g/km
183
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/45 R18 95 Y XL
Tyre dimensions rear
225/45 R18 95 Y XL
Wheel dimensions and material front
7.5 J x 18 inches, light-alloy
Wheel dimensions and material rear
8.5 J x 18 inches, light-alloy

Fuel consumption and CO2 emissions.

  • BMW 320 xDrive Touring:
    Fuel consumption in l/100 km (combined) 5.2
    CO2 emissions in g/km (combined) 137

    The values of the vehicles labeled with (2) are preliminary.

    The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.

    Further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the “handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars”, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html.
