BMW 1 SERIES: TECHNICAL DATA

THE 1BMW 1 SERIES: TECHNICAL DATA

TECHNICAL DATA OF THE BMW 1 SERIES.

Select model

Weight

Unladen weight EU in kg 1,365 [1,395]
Max. permissible weight in kg 1,845 [1,870]
Permitted load in kg 555 [550]
Permitted axle load front/rear in kg 980/940 [1,005/940]
Luggage capacity min. (seats up or roof down) in l 380 [380]
Luggage capacity max. (seats down or roof up) in l 1,200 [1,200]
Trailer load 8% (braked) in kg 1,300 [1,300]
Trailer load 12% (braked) in kg 1,300 [1,300]
Trailer load (unbraked) in kg 680 [695]

Engine

Cylinders/valves 3/4
Capacity in ccm 1,499
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 103 (140)/4,600-6,500
Engine torque (Nm) at 1/min 220/1,480-4,200
Compression ratio : 1 11.0

Performance

Top speed in km/h 211 [211]
Acceleration 0–100 km/h in s 8.5 [8.5]

Fuel consumption

Urban in l/100 km 7.9 [7.0]
Extra–urban in l/100 km 5.3 [5.3]
Combined in l/100 km 6.3 [5.9]
CO2 combined emissions in g/km 143 [135]
Tank capacity, approx. in l 42/50

Wheels

Tyre dimensions front 205/55 R16 91 W
Tyre dimensions rear 205/55 R16 91 W
Wheel dimensions and material front 7 J x 16 inches, steel
Wheel dimensions and material rear 7 J x 16 inches, steel

Weight

Unladen weight EU in kg 1,600
Max. permissible weight in kg 2.085
Permitted load in kg 560
Permitted axle load front/rear in kg 1,120/1,020
Luggage capacity min. (seats up or roof down) in l 380
Luggage capacity max. (seats down or roof up) in l 1,200
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg -
Trailer load (unbraked) in kg -

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 225 (306)/5,000-6,250
Engine torque (Nm) at 1/min 450/1,750-4,500
Compression ratio : 1 9.5

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.8

Fuel consumption

Urban in l/100 km 9.3
Extra–urban in l/100 km 6.4
Combined in l/100 km 7.5
CO2 combined emissions in g/km 171
Tank capacity, approx. in l 50

Wheels

Tyre dimensions front 225/40 R18 92 Y XL
Tyre dimensions rear 225/40 R18 92 Y XL
Wheel dimensions and material front 8 J x 18 inches, light-alloy
Wheel dimensions and material rear 8 J x 18 inches, light-alloy

FUEL CONSUMPTION AND CO2 EMISSIONS OF THE BMW 1 SERIES.

  • BMW M135i xDrive:
    Fuel consumption in l/100 km (combined): 7.5
    CO2 emissions in g/km (combined): 171

    Images show optional equipment, screens and displays depend on equipment options.

    * Depending on the ambient conditions, a temporary peak power is provided, which can be approx. 10% above the nominal power. The duration of the peak power increases as the ambient temperature decreases (approx. 5 sec at +25°C, up to approx. 40 sec at -20°C).

    The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tyres available on the selected model.

    The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.

    For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html.
