BMW 3 Series Sedan, technical data

THE 3

THE BMW 3 SERIES SEDAN: ENGINES & TECHNICAL DATA

THE 3THE BMW 3 SERIES SEDAN: ENGINES & TECHNICAL DATA

TECHNICAL DATA OF THE BMW 3 SERIES SEDAN.

Weight
Unladen weight EU in kg
1,570
Max. permissible weight in kg
2,050
Permitted load in kg
555
Permitted axle load front/rear in kg
965/1,150
Luggage capacity min. (seats up or roof down) in l
480
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,600
Trailer load 12% (braked) in kg
1,600
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
135(184)/5,000-6,500
Engine torque (Nm) at 1/min
300/1,350-4,000
Compression ratio : 1
11.0
Performance
Top speed in km/h
235
Acceleration 0–100 km/h in s
7.1
Fuel consumption
Urban in l/100 km
7.5
Extra-urban in l/100 km
5.6
Combined in l/100 km
6.3
CO2 combined emissions in g/km
144
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
205/60 R16 96W XL
Tyre dimensions rear
205/60 R16 96W XL
Wheel dimensions and material front
6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear
6.5 J x 16 inches, light-alloy
Weight
Unladen weight EU in kg
1.545
Max. permissible weight in kg
2,060
Permitted load in kg
580
Permitted axle load front/rear in kg
985/1,160
Luggage capacity min. (seats up or roof down) in l
480
Luggage capacity max. (seats down or roof up) in l
-
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
1,600
Trailer load 12% (braked) in kg
1,600
Engine
Cylinders/valves
4/4
Capacity in ccm
1,998
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
190 (258)/5,000-6,500
Engine torque (Nm) at 1/min
400/1,550-4,400
Compression ratio : 1
10.2
Performance
Top speed in km/h
250
Acceleration 0–100 km/h in s
5.8
Fuel consumption
Urban in l/100 km
7.9
Extra-urban in l/100 km
5.8
Combined in l/100 km
6.6
CO2 combined emissions in g/km
150
Tank capacity, approx. in l
59
Wheels
Tyre dimensions front
225/50 R17 98Y XL
Tyre dimensions rear
225/50 R17 98Y XL
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy

Fuel consumption and CO2 emissions of the BMW 3 Series Sedan.

  • BMW 330i Sedan:
    Fuel consumption in l/100 km (combined): 6.6
    CO2 emissions in g/km (combined): 150

    BMW 320i Sedan:
    Fuel consumption in l/100 km (combined): 6.4–5.5
    CO2 emissions in g/km (combined): 145–126

    The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.

    Further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the “handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars”, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html.

    Information provided and images displayed on this site include overseas models and features not available in New Zealand. Please contact an authorised BMW dealer for specific information on vehicles and features available in New Zealand. Product changes may have been made since production of this content.
